The ideal solution for making discarded hard drives from personal computers, notebooks, printers and copiers unusable.

At the touch of a button, the IDEAL 0101 HDP punches a hole completely through the hard drive, rendering the stored data unaccessible.

IDEAL 0101 HDP Hard Drive Punch


Main Features
  • At the touch of a button, the IDEAL 0101 HDP punches a hole completely through the hard drive, rendering the stored data unaccessible
  • Suitable for 3.5“ or 2.5“ hard drives (single feeding)
  • Adjustable feed chute constructed of high quality steel
  • Handy slide lever for easy selection of hard drive size (3.5“ or 2.5“)
  • Transparent safety flap on the feed chute made of unbreakable plastic
  • Punching die made from hardened, nickel-plated steel | sturdy steel endplate
  • LEDs for illuminating the feed chute during the punching process
  • Slider mechanism for unloading punching compartment
  • Destroyed hard drives drop into a sturdy plastic bin inside the cabinet
  • High-quality wooden cabinet with front opening door | quiet and powerful 640 watt single phase motor rated for continuous operation
  • Sturdy ”Twin Drive System“ with fully enclosed gear box housing
  • SPS (Safety Protection System) safety package
  • Electronically controlled, hinged safety flap for the feed opening
  • EASY_SWITCH multifunction control element for start and stop indicates the operational status of the machine with varying colour codes and back-lit symbols
  • Jam protection for punching die with automatic reverse
  • Automatic stop after the punching process
  • Weight sensor for automatic shut-off when the collection bin is full
  • Electronic door protection via a magnetic proximity switch
  • Double motor protection


Technical Specifications:

  • Power 230 V / 50 Hz
  • Motor capacity 640 Watt single phase motor
  • Dimensions 850 x 495 x 470 mm (H x W x D)
  • Weight 63 kg
  • Level H-3 3,5˝ / 2,5˝ Hard Disks
  • Punching cycle: 15 s
